This course is devoted to the more widely used sharp-crested weir.
A weir is basically an obstruction in an open channel flow path. Weirs are commonly used for measurement of open channel flow rate. A weir functions by causing water to rise above the obstruction in order to flow over it. The height of water above the obstruction correlates with the flow rate, so that measurement of the height of the flowing water above the top of the weir can be used to determine the flow rate by the use of an equation, graph or table. The top of the weir, which is used as the reference level for the height of water flowing over it, is called the crest of the weir. Weirs are typically classified as being either sharp-crested or broad-crested. This course is devoted to the more widely used sharp-crested weir. The major emphasis is on the calculations used for flow rate over various types of sharp-crested weirs. There is also information about guidelines for the installation and use of sharp-crested weirs.
Topics: Sharp-Crested Weir Background V-notch Weirs Suppressed Rectangular Weirs Contracted Rectangular Weirs Cipolletti Weirs Installation and Use Guidelines for Sharp-Crested Weirs
At the conclusion of this course, the student will Be familiar with standard terminology used in connection with sharp-crested weirs for open channel flow measurement. Be able to use the Kindsvater-Carter equation to calculate the flow rate over a suppressed rectangular weir for given head over the weir and weir dimensions. Be able to use the Kindsvater-Carter equation to calculate the flow rate over a contracted rectangular weir for given head over the weir and weir dimensions. Know the conditions required in order to use a simpler equation instead of the Kindsvater-Carter equation to calculate the flow rate over a suppressed rectangular weir and over a contracted rectangular weir for given head over the weir and weir dimensions. Know the conditions required in order to use the equation, Q = 2.49 H2.48, to calculate the flow rate over a V-notch weir for given head over the weir and weir dimensions. Be able to use the Kindsvater-Carter equation to calculate the flow rate over a V-notch weir for notch angles other than 90o, given head over the weir and weir dimensions. Be familiar with installation and use guidelines for sharp-crested weirs for open channel flow measurement.
